All Mattei compressors in the GAS range comply with the requirements of the Atex (Atmosphères Explosives) directives.
Mattei gas compressors work at full capacity 24/7
The rotor, blades, stator and covers are made entirely of cast iron. This construction feature ensures:
A particular software performs a feedback control function, before the gas is introduced into the compressor, checking that the suction pressure is compliant with the parameters set based on the request.
Mattei compressors' multi-stage filtration system guarantees excellent gas quality.
Thanks to their compact design, the installation of GAS compressors is quick and space-saving.
The range of GAS compressors with power ratings from 4kW up to 200 kW is available as stand-alone units for OEM applications or according to customer specifications. All versions are complete with automatic flow rate control at constant pressure, integrated or remote radiator and threaded or flanged gas inlet device.
Possibility to create customised solutions, for specific applications or critical environmental conditions.
| Rated power | 4 to 200 kW |
| F.A.D. | 0.4 to 35.3 m3/min |
| Working pressures | 7/10/13 bar |
| Compression technology | Rotary Vane |
| Output | 0% to 100% |
| Drive system | Direct coupled with elastic element |
| Cooling | Air/water – Integrated or remote panel cooler |
| Temperature protection | Thermistor |
| Controller | Fully customisable remote PLC control Maestro XS |
| Pressure Control | Servo with modulation - Pressure sensor - External signal Reference |
| Pressure protection | Safety valve |
| Operating ambient range | 5C to + 45C (23F to + 113F) |
| Inlet pressure range | 0 to 650mbar (0 to 8.7psi) |
| Acceptable gases | Sweet Gas Sour Gas Bio Gas |
| Maximum allowable free moisture | None |
| Maximum allowable H2S | 800ppm |
| Lubricant | Mattei V-Life Gas |
| Laws and conformity | 2006/42/EC – Machinery directive 92/27/CW PED - directive on pressure equipment 94/9/CE – ATEX - Systems intended for use in potentially explosive atmospheres |
| Optional Feature | Active Zener Barrier |
They undergo a rigorous performance evaluation and quality management programme to ensure optimal operation of the air compressors.
Qualified after-sales service offering a wide range of services and able to respond to any service request in a very short time.
The American company, Glauber Equipment Corporation, has put in place a system for the treatment of biogas, which has made use of the Mattei compressors dedicated for gas applications. The systems, purchased by Belgian company Waterlau, are destined to be part of a much larger project, commissioned by the Mexican beer giant, Grupo Modelo.
Mattei Germany - partner of the Austrian energy producer and distributor in the field of micro-cogeneration.
Mattei compressors are the leaders of the biogas updrading system created by Ammongas, a Danish company.
Mattei offers a wide range of vane compressor models that perfectly meet the specific needs of the transport industry.
The reliability of Mattei compressors, the high quality standards of the delivered compressed air and the compliance with the industry regulations, make them ideal to be used in the healthcare and pharmaceutical industry.
Reduced operating costs, environmental sustainability and extreme purity of the air supplied make Mattei compressors suitable for all processes in the food industry.
